Production process of PVC gusset production line

Production process of PVC gusset production line：

The PVC raw materials are stirred by the screw feeder to the high-speed mixer unit at high speed. The PVC raw materials are fully mixed in the hot mixer, and when the appropriate temperature is reached, they are automatically placed in the cold mixer and stirred at a low speed of 40~50°, and then the spring feeder is sent to the twin-screw. The extruder, where the PVC raw material begins to be plasticized, is extruded through the mold, and then is shaped by the setting die on the vacuum setting table through vacuuming and cooling water, and is automatically pulled by the tractor, and the speed of the tractor is adjusted to make the extruder. The extrusion is synchronized with the tractor, and the rotary encoder is placed on the gusset plate at the exit of the tractor. The rotary encoder starts to automatically record the meter and set the length, and reaches the set length. Finally, the material is automatically stacked by the stacker.
