Agricultural Film
Agricultural Film
Woven Bag
Rigid flakes
Waste Bottle
Soft Flakes (PE PP HDPE LDPE Film/Bag etc)
Rigid flakes （PE PP PET Bottle/Pipe/Sheet etc）
Application plastic material: PE ,HDPE,LDPE,PP,BOPP etc.
Material shapes: crushed rigid materials, bottle flakes.
Note: depending on different material properties, various downstream equipment are needed.
Special designed side force feeder with high capacity for crushed washed dry flakes.
Adopting single / double stage extrusion line with more stable and reliable capacity.
Die face (Water-ring type/String type) cutting for option.
1. Remove labels,cap from waste bottles(film/bag not need)
2. Remove rate:>=95%
3. With water / without water
4. Photo show without water
1.Crush big material to small flakes
2.Quantity of strands:300-1000kg/h
1.Add detergent (NaOH etc) ,hot water clean oil,glue,soil etc
2.Heating:Steam boiler(150-1000kg) or Electric heat
1.Clean detergent,soil etc
2.With blowdown screw
1.Adopt high speed to clean glue and dirty from flakes
1.Remove water from flakes
2.Moisture content<=3%
If you are finding a Trustworthy Long-Term Oversea
Plastic Extrusion Manufacurer Partner ?
Output | 500kg/h | 1000kg/h | 2000kg/h | 3000kg/h | 3500kg/h |
Workshop (L x W x H) | 42m x 10m x 6m | 50m x 15m x 6m | 80m x 18m x 6m | 100m x 25m x 6m | 110m x 25m x 6m |
Installation power | 110kw | 246kw | 410kw | 750kw | 1050kw |
Water supply | 3m3/h | 3m3/h | 3m3/h | 4m3/h | 5m3/h |
Steam | 300kg/h | 500kg/h | 800kg/h | 1000kg/h | 1000kg/h |
Manpower | 4 | 5 | 6 | 7 | 8 |
Final product feature | Moisture:<2% Bulk density:0.3g/cm3 Particle size:8-16mm PVC content:100ppm Metal content:20ppm PE PP content:200ppm Total impurity content:320ppm | ||||
Output | 300kg/h | 500kg/h | 2000kg/h | 2000kg/h |
Workshop (L x W x H) | 40m x 10m x 6m | 40m x 10m x 6m | 45m x 15m x 6m | 80m x 18m x 6m |
Installation power | 170kw | 245kw | 315kw | 410kw |
Water supply | 3m3/h | 3m3/h | 3m3/h | 3m3/h |
Steam | 150kg/h | 200kg/h | 400kg/h | 500kg/h |
Manpower | 4 | 54 | 4 | 6 |
| Final product feature | Moisture:<7% Bulk density:0.1g/cm3 Particle size:30-60mm Total impurity content:150ppm | |||
